CAMERA

Model BL-854N38S-S7

Image Sensor 1/3” CMOS Sensor

Effective Pixels 2560*1440

Min. Illumination

Color: 0.01Lux@F1.2-2.2 (AGC ON)

B/W: 0.001Lux@F1.2-2.2 (IR ON)

Flash / DDR 128MB / 512MB

IR LED No. 2

IR Distance 50m

S/N Ratio >52dB

LENS

Lens Type Motorized

Mount Type Board-in

Focal Length 2.8-12mm

Aperture F1.2 – F2.2

FOV 37°~98°

Optical Zoom Support

VIDEO

Compression H.265, H.264

Resolution 4MP (2560 x 1440) / 3MP (2304 x 1296) / 1080P (1920 x 1080) / 1.3MP (1280 x 960) / 720P (1280 x 720)

Bitrate Control CBR / VBR

Bitrate 1792Kbps ~ 6Mbps

Multi-Streaming

Main Stream: 4MP@20fps / 3MP@25fps / 1080P@25fps / 960P@25fps / 720P@25fps

Sub Stream: D1@25fps / VGA@25fps / CIF@25fps

Third Stream: N/A

Motion Detection Support

Digital Zoom Support

Audio Compression G.711u

Privacy Mask 4 areas

WDR DWDR

Day / Night Support

White Balance Support

Defog N/A

Noise Reduction 2D / 3D DNR

Mirror / Flip Support

Corridor Mode Support

HLC Support

BLC Support

ROI 4 areas

Anti-flicker N/A

IVA

Intelligent Video N/A

FACE DETECTION

Face Templates N/A

Face Detected Per Frame N/A

Detected Face Size N/A

Face Quality Filtering N/A

Detection Area N/A

Capture Response N/A

NETWORK

Protocol TCP/IP, UDP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IPv4, SSL/TLS

Interoperability ONVIF Profile S, SDK, API

Max. Online Users 3

Web Browser IE / Firefox / Chrome / Safari

Management Software (VMS)

AntarVis 2.0

ZKBioSecurity IVS

ZKBioAccess IVS

Operation System Windows

Mobile APP AntarView Pro

P2P Cloud Service Support

INTERFACE

Ethernet 1*RJ-45 port (10 / 100Mbps)

Audio I/O 1/0

Alarm I/O N/A

RS485 N/A

Reset Button N/A

Micro-SD Slot N/A

ANR N/A

USB N/A

GENERAL

Power Supply PoE (IEEE802.3af ), DC 12V±10%

Power Consumption < 3W

Dimensions 246 * 85 * 76 (mm)

Ingress Protection Rating IP67

Operating Temperature -30°C ~ 60°C

Operating Humidity 10% ~ 90%

Net Weight 0.50kg

Gross Weight 0.70kg
